Product Details
Place of Origin: CHINA
Brand Name: changlin
Model Number: 630
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD5000-USD100000
Delivery Time: 5-8work days
Payment Terms: L/C, T/T
Supply Ability: 30units/per month
Model: |
630 |
Length (with Bucket On Ground) (mm): |
7085 |
Width (mm): |
2313 |
Load Bucket Width (mm): |
2313 |
Height (To The Top Of The Cab) (mm): |
2710 |
Height (To The Top Of The Digging Pole) (mm): |
3424 |
Wheelbase (mm): |
2155.5 |
Min. Ground Clearance (mm): |
275 |
Rated Load (Kg): |
1700 |
Operating Weight: |
7600 |
Rated Digging Bucket Capacity (m3): |
1.0 |
Max. Dump Clearance (mm): |
2714 |
Dump Reach (mm): |
845 |
Max Lifting Capability (Kg): |
3400 |
Max. Load Breakout Force (kN): |
>60 |
Rated Digging Bucket Capacity (m3): |
0.3 |
Max. Digging Depth (mm): |
4405 |
Max. Digging Radius (mm): |
5481 |
Max. Digging Force (kN): |
>50+10％ |
Engine Model: |
WD DEUTZ WP4G95E221 /Cummins 4BTA3.9-C110 |
Rated Output: |
70 (kW)@2200rpm /82 (kW)@2200rpm |
Name: |
Backhoe Excavator Loader |
Model: |
630 |
Length (with Bucket On Ground) (mm): |
7085 |
Width (mm): |
2313 |
Load Bucket Width (mm): |
2313 |
Height (To The Top Of The Cab) (mm): |
2710 |
Height (To The Top Of The Digging Pole) (mm): |
3424 |
Wheelbase (mm): |
2155.5 |
Min. Ground Clearance (mm): |
275 |
Rated Load (Kg): |
1700 |
Operating Weight: |
7600 |
Rated Digging Bucket Capacity (m3): |
1.0 |
Max. Dump Clearance (mm): |
2714 |
Dump Reach (mm): |
845 |
Max Lifting Capability (Kg): |
3400 |
Max. Load Breakout Force (kN): |
>60 |
Rated Digging Bucket Capacity (m3): |
0.3 |
Max. Digging Depth (mm): |
4405 |
Max. Digging Radius (mm): |
5481 |
Max. Digging Force (kN): |
>50+10％ |
Engine Model: |
WD DEUTZ WP4G95E221 /Cummins 4BTA3.9-C110 |
Rated Output: |
70 (kW)@2200rpm /82 (kW)@2200rpm |
Name: |
Backhoe Excavator Loader |
Utilizing Cummins 4BTA3.9-C110 engine or Weichai engine, delivering high digging force, superior performance, excellent energy-saving efficiency, low maintenance cost, outstanding reliability and durability.Maintenance-free wet brake system has dual brake pedals, which ensure smooth braking in limited spaces and tight corners.More backhoe loader attachments are available for customers to choose from.Hydraulic system includes high quality hydraulic components from world's renowned brands to ensure reliable operation, and the additional hydraulic circuit allows to cope with the digging and loading works.The backhoe loader has eight-bar-linkage design to improve loading performance with powerful bucket breakout force and high work stability. More importantly, the automatic bucket leveling system helps operator maintain high work efficiency.FOPS/ROPS certified spacious cab provides excellent operator visibility.
Maintenance-free wet brake system has dual brake pedals, which ensure smooth braking in limited spaces and tight corners.
The backhoe loader has eight-bar-linkage design to improve loading performance with powerful bucket breakout force and high work stability. More importantly, the automatic bucket leveling system helps operator maintain high work efficiency.
FOPS/ROPS certified spacious cab provides excellent operator visibility.
