GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output

Name: GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output
Brand: CHANGLIN WEA CO., LTD
SKU: GT160
Price: 24,999.00 USD
Availability: InStock

Product Details

Place of Origin: China

Brand Name: Changlin

Certification: Provided

Model Number: GT160

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: USD20000-29999

Packaging Details: Nude

Delivery Time: 7-14 working days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 30set/momth

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    GTY160 Hydraulic Controlled Bulldozer, Hydraulic Controlled Bulldozer Equipment


Model:	GTY160	Displacement (L):	9.726
Rated Power(kw/rpm):	131/1850	Max.torque (N.m/rpm):	830/1000-1200
Operation Weight:	16.4T	Dimension (no Ripper) (mm):	499034403310
Ground Pressure (MPa):	0.067	Track Gauge (mm):	1880
Dozing Capacity(m³):	4.55	Blade Width (mm):	3440
Blade Height (mm):	1135	Max.drop Below Ground (mm):	540
Track Shoe Width (mm):	510	Pitch (mm):	203.2

Model:	GTY160
Displacement (L):	9.726
Rated Power(kw/rpm):	131/1850
Max.torque (N.m/rpm):	830/1000-1200
Operation Weight:	16.4T
Dimension (no Ripper) (mm):	499034403310
Ground Pressure (MPa):	0.067
Track Gauge (mm):	1880
Dozing Capacity(m³):	4.55
Blade Width (mm):	3440
Blade Height (mm):	1135
Max.drop Below Ground (mm):	540
Track Shoe Width (mm):	510
Pitch (mm):	203.2

Description

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output

BULLDOZER GTY160

The GTY160 hydraulic bulldozer utilizes new technology and rational design for higher power output, greater work efficiency and less maintenance cost. It can accommodate challenging operating conditions.

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 0

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 1

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 2

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 3

FEATURES

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 4

1.Engine side cover facilitates maintenance access, and a handle is added for operator's safety during the repairing process.

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 5

2.The bulldozer is designed with a new cab, giving a superior look and increased visibility.

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 6

3.The ergonomic cab design enables increased interior space, easy-to-use joystick controls keep the operator more comfortable and make work easier and more precise with less labor intensity. The use of adjustable seat, improved steering and vibration-damping floor efficiently minimizes the vibration transmitted into cab under severe working conditions, thus further improving operator's comfort.

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 7

4.Engine side cover facilitates maintenance access, and a handle is added for operator's safety during the repairing process.

GTY160 Hydraulic Controlled Bulldozer Equipment For Higher Power Output 8

5.The bulldozer is designed with a new cab, giving a superior look and increased visibility.
