Product Details
Place of Origin: CHINA
Brand Name: changlin
Model Number: GTY220
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD5000-USD100000
Delivery Time: 5-8work days
Payment Terms: L/C, T/T
Name: |
Crawler Bulldozer Construction Equipment |
Model: |
GTY220 |
Displacement (L): |
14.01 |
Rated Power(kW/rpm): |
175/1800 |
Max. Torque (N.m/rpm): |
1030/1250 |
Operating Weight: |
23.5 Ton |
Dimension (no Ripper) (mm): |
5390×3735×3350 |
Ground Pressure (MPa): |
0.077 |
Track Gauge (mm): |
2000 |
Dozing Capacity (m³): |
6.4 |
Blade Width (mm): |
3735 |
Blade Height (mm): |
1310 |
Track Shoe Width (mm): |
560 |
Max. Tractor Force (KN): |
202 |
Name: |
Crawler Bulldozer Construction Equipment |
Model: |
GTY220 |
Displacement (L): |
14.01 |
Rated Power(kW/rpm): |
175/1800 |
Max. Torque (N.m/rpm): |
1030/1250 |
Operating Weight: |
23.5 Ton |
Dimension (no Ripper) (mm): |
5390×3735×3350 |
Ground Pressure (MPa): |
0.077 |
Track Gauge (mm): |
2000 |
Dozing Capacity (m³): |
6.4 |
Blade Width (mm): |
3735 |
Blade Height (mm): |
1310 |
Track Shoe Width (mm): |
560 |
Max. Tractor Force (KN): |
202 |
The GTY220 bulldozer is versatile construction equipment used for pushing, digging, excavating and leveling materials such as soil at roads, railways, mines, airports, and other jobsites. It is crucial piece of heavy equipment for construction projects in fields of national defense, mining, urban/rural roads and water conservancy.
The front and rear hoods adopt grill type semi-sealed structure for better heat dissipation. It also provides the comprehensive protection of the engine, and significantly lowers noise level.
The spacious hexahedral cab with large glass door and windows provide excellent panoramic visibility for more safe and efficient work. In addition, the luxurious interior of the cab gives superior look and soundproofing materials minimize noise levels while providing good heat insulation and sealing effect.
The GTY16 hydraulic bulldozer adopts the central transmission assembly which is a transmission system between the gearbox and the final drive, with the purpose to change the transmission torque and direction. The power is transmitted to steering clutch and final drive gear to enable the bulldozer to travel, steer and brake, providing smooth control and excellent mechanical efficiency.
A variety of bulldozer attachments are available for superior performance in customer-specific application tasks. Special attachments can be provided as per customer request.
