Product Details
Place of Origin: CHINA
Brand Name: CHANGLIN/SINOMACH
Model Number: CPCD40
Payment & Shipping Terms
Minimum Order Quantity: one unit
Price: usd29000/unit-usd36000/unit
Packaging Details: by container
Delivery Time: 20 working days
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 5000 units per year
Product Model: |
CPCD40 |
Ground Clearance (bottom Of Mast) (mm): |
170 |
Power Type: |
Diesel |
Length×Width×Height(mm): |
2780×1225×2150 |
Operating Weight(Kg): |
6300 |
Rated Capacity(Kg): |
4000 |
Load Center(mm): |
500 |
Lift Height(mm): |
3000 |
Fork Size(mm): |
1070×122×50 |
Turning Radius(mm): |
2690 |
Diesel Engine Type: |
Cummins Or Perkins |
Rated Output(KW): |
60/56 |
Product Model: |
CPCD40 |
Ground Clearance (bottom Of Mast) (mm): |
170 |
Power Type: |
Diesel |
Length×Width×Height(mm): |
2780×1225×2150 |
Operating Weight(Kg): |
6300 |
Rated Capacity(Kg): |
4000 |
Load Center(mm): |
500 |
Lift Height(mm): |
3000 |
Fork Size(mm): |
1070×122×50 |
Turning Radius(mm): |
2690 |
Diesel Engine Type: |
Cummins Or Perkins |
Rated Output(KW): |
60/56 |
Sinomach Changlin CPCD40 diesel forklift truck rated capacity 4000kg Cummins engine or Perkins
· With up to date appearance design, the CPCD40N series diesel forklift features streamline, dynamic and stylish appearance.
· Large sized covering part made by injection molding process makes the lift truck more elegant and user friendly.
· Long wheelbase design ensures higher longitudinal stability and more than 100kg lifting weight higher than the original forklift truck at the same lifting height. Load on the real axle is also reduced, prolonging the service life of steering wheel.
· Reduction of front and rear overhang size ensures smaller turning radius and lower width of passage for right angle stacking, thus improving warehouse use ratio.
· The diesel powered forklift can be equipped with Japanese OKAMURA, NISSAN and Chinese HC transmissions that come with best in class structure and reliable performance. Among which, the OKAMURA transmission applies the state of the art floating structure, ensuring completely flexible connection between engine and forklift frame, thus minimizing vibration.
