DIESEL FORKLIFT CPCD35

Name: DIESEL FORKLIFT CPCD35
Brand: CHANGLIN WEA CO., LTD
SKU: CPCD35
Price: Negotiable USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: changlin

Model Number: CPCD35

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD5000-USD100000

Delivery Time: 5-8work days

Payment Terms: L/C, T/T

Supply Ability: 30units/per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    CPCD35 DIESEL FORKLIFT


Model:	CPCD35	Power Type:	Diesel
Rated Load Capacity (kg):	3500	Load Centre (mm):	500
Rated Lift Height (mm):	3000	Free Lift Height (mm):	165
Fork Size (L×W×T) (mm):	107012250	Mast Tilt Angle (F/R, α°/β°):	6°/12°
Fork Overhang (wheel Center To Fork Face) (mm):	480	Ground Clearance (bottom Of Mast) (mm):	130
Length To Face Of Fork (without Fork) (mm):	2780	Overall Width (wheel) (mm):	1225
Overhead Guard Height (mm):	2150	Wheelbase (mm):	1700
Turning Radius (outside) (mm):	2440	Travel Speed (loaden/unloaden) (km/h):	18/19
Lifting Speed (loaden/unloaden) (mm/s):	380/450	Lowering Speed (loaden/unloaden) (mm/s):	400/350
Max. Gradeability (loaden/unloaden) (%):	20/20	Engine Model:	C490BPG
Rated Power:	40kW@2650rpm	Rated Torque:	160N.m @1800-2000rpm

Model:	CPCD35
Power Type:	Diesel
Rated Load Capacity (kg):	3500
Load Centre (mm):	500
Rated Lift Height (mm):	3000
Free Lift Height (mm):	165
Fork Size (L×W×T) (mm):	107012250
Mast Tilt Angle (F/R, α°/β°):	6°/12°
Fork Overhang (wheel Center To Fork Face) (mm):	480
Ground Clearance (bottom Of Mast) (mm):	130
Length To Face Of Fork (without Fork) (mm):	2780
Overall Width (wheel) (mm):	1225
Overhead Guard Height (mm):	2150
Wheelbase (mm):	1700
Turning Radius (outside) (mm):	2440
Travel Speed (loaden/unloaden) (km/h):	18/19
Lifting Speed (loaden/unloaden) (mm/s):	380/450
Lowering Speed (loaden/unloaden) (mm/s):	400/350
Max. Gradeability (loaden/unloaden) (%):	20/20
Engine Model:	C490BPG
Rated Power:	40kW@2650rpm
Rated Torque:	160N.m @1800-2000rpm

Description

DIESEL FORKLIFT CPCD35

DIESEL FORKLIFTCPCD35

The diesel forklift offers enhanced operational visibility through an increased inside width of the inner mast and the distance between inner mast rails. The forward visibility is greatly improved by lowering the instrument panel, and the rearward visibility is enhanced by improving the design of counterweight;

The enlarged opening angle of hood and addition of left and right hood side plates make the maintenance of the forklift easier and quicker;

Large size tapered roller bearing (TRB) is used on the steering axle king pin, larger steering cylinder and bumper block assemblies are employed for longer service life of bearing and improved reliability of steering axle;

The engine of diesel forklift provides high power output, low emission and good cold starting performance, the energy consumption is reduced by 10%;

The overhead guard is fabricated using special-shaped steel tube, ensuring reinforced strength and improved sealing of cab;

The new generation of integrated electric box is adopted in the diesel forklift for easy maintenance and repairing, it has reasonable layout and good water-proof performance;
