Product Details
Place of Origin: China
Brand Name: Changlin
Certification: Provided
Model Number: CPCD25
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 1000-10000
Packaging Details: Nude
Delivery Time: 7-10days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 90 set/momth
Model: |
CPCD30 |
Power Type: |
Diesel |
Rated Load Capacity(kg): |
3000 |
Load Center(mm): |
500 |
Free Lift Height(mm): |
165mm |
Fork Size(L*W*H)(mm): |
1070*122*45 |
Mast Tilt Angle(F/R, α°/β°): |
6°/12° |
Fork Overhang (Wheel Center To Fork Face) (mm): |
475 |
Ground Clearance (Bottom Of Mast) (mm): |
130 |
Length To Face Of Fork (Without Fork) (mm): |
2700 |
Overall Width (Wheel) (mm): |
1225 |
Overhead Guard Height (mm): |
2150 |
Wheel Base (mm): |
1700 |
Turning Radius (Outside) (mm): |
2400 |
Travel Speed (loaden/unloaden) (km/h): |
18/19 |
Lifting Speed (loaden/unloaden) (mm/s): |
460/500 |
Lowering Speed (loaden/unloaden) (mm/s): |
500/450 |
Max.Gradeability (loaden/unloaden) %: |
25/25 |
Tyre (Front ): |
28*9-15-14PR |
Tyre (Rear ): |
6.50-10-10PR |
Total Weight (kg): |
4380 |
Engine Model: |
C490BPG |
Rated Power: |
40kw 2650rpm |
Rated Torque: |
160N.m 1800-2000rpm |
Name: |
Forklift Truck |
Model: |
CPCD30 |
Power Type: |
Diesel |
Rated Load Capacity(kg): |
3000 |
Load Center(mm): |
500 |
Free Lift Height(mm): |
165mm |
Fork Size(L*W*H)(mm): |
1070*122*45 |
Mast Tilt Angle(F/R, α°/β°): |
6°/12° |
Fork Overhang (Wheel Center To Fork Face) (mm): |
475 |
Ground Clearance (Bottom Of Mast) (mm): |
130 |
Length To Face Of Fork (Without Fork) (mm): |
2700 |
Overall Width (Wheel) (mm): |
1225 |
Overhead Guard Height (mm): |
2150 |
Wheel Base (mm): |
1700 |
Turning Radius (Outside) (mm): |
2400 |
Travel Speed (loaden/unloaden) (km/h): |
18/19 |
Lifting Speed (loaden/unloaden) (mm/s): |
460/500 |
Lowering Speed (loaden/unloaden) (mm/s): |
500/450 |
Max.Gradeability (loaden/unloaden) %: |
25/25 |
Tyre (Front ): |
28*9-15-14PR |
Tyre (Rear ): |
6.50-10-10PR |
Total Weight (kg): |
4380 |
Engine Model: |
C490BPG |
Rated Power: |
40kw 2650rpm |
Rated Torque: |
160N.m 1800-2000rpm |
Name: |
Forklift Truck |
CPCD30 Diesel forklifT
FEATURES
•Adopt the new-type of box iron. Increase the inside width of inner mast and the spacing between lifting cylinders. The lowering of instruments in the cabin will greatly increase the forward visibility; The rear visibility will also be greatly improved through the optimization design of counterweight.
•The enlarged opening angle of hood and increase of left and right hood side plates can provide you with convenient and rapid maintenance mode.
· Roller bearing on the steering axle king pin adopts large size tapered roller bearing (TRB), larger steering cylinder and bumper block assemblies on the top, which can prolong the service life of bearing and highly improve the reliability of steering axle.
·The engine ensure the strong power take-off, lower emission and better cold starting performance; saving the 10% of energy consumption.
· overhear guard adopts special-shaped steel tube, which can reinforce the strength and improve sealing of the cab.
·Adoption of new generation integrated electric box makes maintenance and repair convenient, layout becomes more reasonable and with better water-proof performance.
