Product Details
Place of Origin: China
Brand Name: Changlin
Certification: Provided
Model Number: CPCD35
Payment & Shipping Terms
Minimum Order Quantity: 1 set
Price: 10000-12000
Packaging Details: Nude
Delivery Time: 7-10days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 90 set/momth
Model: |
CPCD35 |
Power Type: |
Diesel |
Rated Load Capacity(kg): |
3500 |
Load Center(mm): |
500 |
Free Lift Height(mm): |
165mm |
Fork Size(L*W*H)(mm): |
1070*122*50 |
Mast Tilt Angle(F/R, α°/β°): |
6°/12° |
Fork Overhang (Wheel Center To Fork Face) (mm): |
480 |
Ground Clearance (Bottom Of Mast) (mm): |
130 |
Length To Face Of Fork (Without Fork) (mm): |
2780 |
Overall Width (Wheel) (mm): |
1225 |
Overhead Guard Height (mm): |
2150 |
Wheel Base (mm): |
1700 |
Turning Radius (Outside) (mm): |
2440 |
Travel Speed (loaden/unloaden) (km/h): |
18/19 |
Lifting Speed (loaden/unloaden) (mm/s): |
380/450 |
Lowering Speed (loaden/unloaden) (mm/s): |
400/350 |
Max.Gradeability (loaden/unloaden) %: |
20/20 |
Tyre (Front ): |
28*9-15-14PR |
Tyre (Rear ): |
6.50-10-10PR |
Total Weight (kg): |
4750 |
Engine Model: |
C490BPG |
Rated Power: |
40kw 2650rpm |
Rated Torque: |
160N.m 1800-2000rpm |
Name: |
Hydraulic Forklift CPCD35 |
Model: |
CPCD35 |
Power Type: |
Diesel |
Rated Load Capacity(kg): |
3500 |
Load Center(mm): |
500 |
Free Lift Height(mm): |
165mm |
Fork Size(L*W*H)(mm): |
1070*122*50 |
Mast Tilt Angle(F/R, α°/β°): |
6°/12° |
Fork Overhang (Wheel Center To Fork Face) (mm): |
480 |
Ground Clearance (Bottom Of Mast) (mm): |
130 |
Length To Face Of Fork (Without Fork) (mm): |
2780 |
Overall Width (Wheel) (mm): |
1225 |
Overhead Guard Height (mm): |
2150 |
Wheel Base (mm): |
1700 |
Turning Radius (Outside) (mm): |
2440 |
Travel Speed (loaden/unloaden) (km/h): |
18/19 |
Lifting Speed (loaden/unloaden) (mm/s): |
380/450 |
Lowering Speed (loaden/unloaden) (mm/s): |
400/350 |
Max.Gradeability (loaden/unloaden) %: |
20/20 |
Tyre (Front ): |
28*9-15-14PR |
Tyre (Rear ): |
6.50-10-10PR |
Total Weight (kg): |
4750 |
Engine Model: |
C490BPG |
Rated Power: |
40kw 2650rpm |
Rated Torque: |
160N.m 1800-2000rpm |
Name: |
Hydraulic Forklift CPCD35 |
CPCD35 Diesel forklifT
FEATURES
•The diesel forklift offers enhanced operational visibility through an increased inside width of the inner mast and the distance between inner mast rails. The forward visibility is greatly improved by lowering the instrument panel, and the rearward visibility is enhanced by improving the design of counterweight;
•Large size tapered roller bearing (TRB) is used on the steering axle king pin, larger steering cylinder and bumper block assemblies are employed for longer service life of bearing and improved reliability of steering axle;
· The overhead guard is fabricated using special-shaped steel tube, ensuring reinforced strength and improved sealing of cab;
·The enlarged opening angle of hood and addition of left and right hood side plates make the maintenance of the forklift easier and quicker;
· The engine of diesel forklift provides high power output, low emission and good cold starting performance, the energy consumption is reduced by 10%;
·The new generation of integrated electric box is adopted in the diesel forklift for easy maintenance and repairing, it has reasonable layout and good water-proof performance;
