CPCD50 Forklift Equipment , 5 Ton Electric Forklift Easy Maintenance

Name: CPCD50 Forklift Equipment , 5 Ton Electric Forklift Easy Maintenance
Brand: CHANGLIN WEA CO., LTD
SKU: CPCD50
Price: Negotiable USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: changlin

Model Number: CPCD50

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD5000-USD100000

Delivery Time: 5-8work days

Payment Terms: L/C, T/T

Supply Ability: 30units/per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                    CPCD50 Forklift Equipment, 5 Ton Electric Forklift


Model:	CPCD50	Power Type:	Diesel
Rated Load Capacity (kg):	5000	Load Centre (mm):	500
Rated Lift Height (mm):	3000	Free Lift Height (mm):	160
Fork Size (L×W×T) (mm):	107015050	Mast Tilt Angle (F/R, α°/β°):	6°/12°
Fork Overhang (wheel Center To Fork Face) (mm):	555	Ground Clearance (Bottom Of Mast) (mm):	150
Length To Face Of Fork (without Fork) (mm):	3175	Overall Width (wheel) (mm):	1490
Overhead Guard Height (mm):	2310	Wheelbase (mm) 2000:	2000
Turning Radius (outside) (mm):	2780	Travel Speed (loaden/unloaden) (km/h):	23.5/25
Lifting Speed (loaden/unloaden) (mm/s):	400/440	Lowering Speed (loaden/unloaden) (mm/s):	460/440
Max. Gradeability (loaden/unloaden) (%):	20/23	Total Weight (kg):	6750
Engine Model:	LR4B3	Rated Power:	57kw@2200rpm
Rated Torque:	285N.m@1400rpm	Name:	5 Ton Electric Forklift

Model:	CPCD50
Power Type:	Diesel
Rated Load Capacity (kg):	5000
Load Centre (mm):	500
Rated Lift Height (mm):	3000
Free Lift Height (mm):	160
Fork Size (L×W×T) (mm):	107015050
Mast Tilt Angle (F/R, α°/β°):	6°/12°
Fork Overhang (wheel Center To Fork Face) (mm):	555
Ground Clearance (Bottom Of Mast) (mm):	150
Length To Face Of Fork (without Fork) (mm):	3175
Overall Width (wheel) (mm):	1490
Overhead Guard Height (mm):	2310
Wheelbase (mm) 2000:	2000
Turning Radius (outside) (mm):	2780
Travel Speed (loaden/unloaden) (km/h):	23.5/25
Lifting Speed (loaden/unloaden) (mm/s):	400/440
Lowering Speed (loaden/unloaden) (mm/s):	460/440
Max. Gradeability (loaden/unloaden) (%):	20/23
Total Weight (kg):	6750
Engine Model:	LR4B3
Rated Power:	57kw@2200rpm
Rated Torque:	285N.m@1400rpm
Name:	5 Ton Electric Forklift

Description

CPCD50 Forklift Equipment , 5 Ton Electric Forklift Easy Maintenance

DIESEL FORKLIFTCPCD50

The diesel forklift offers enhanced operational visibility through an increased inside width of the inner mast and the distance between inner mast rails. The forward visibility is greatly improved by lowering the instrument panel, and the rearward visibility is enhanced by improving the design of counterweight;

Heavy-duty chassis or flexible type chassis is optional;

The enlarged opening angle of hood and addition of left and right hood side plates make the maintenance of the forklift easier and quicker;

The engine of diesel forklift provides high power output, low emission and good cold starting performance, the energy consumption is reduced by 10%;

The new generation of integrated electric box is adopted in the diesel forklift for easy maintenance and repairing, it has reasonable layout and good water-proof performance;

Large size tapered roller bearing (TRB) is used on the steering axle king pin, larger steering cylinder and bumper block assemblies are employed for longer service life of bearing and improved reliability of steering axle;
