Heavy Earth Moving Machinery ZG150 Ergonomic Design With Spacious Driving Space

hydraulic excavator

ZG150

Unearthing Potential with the ZG150 Crawler Hydraulic Excavator

The ZG150 Crawler Hydraulic Excavator is a testament to the power and efficiency required for a wide range of excavation tasks. Designed to deliver outstanding performance in the most challenging conditions, this robust machine is a must-have for any construction or mining project.

**Operating Weight:** The ZG150 boasts an impressive operating weight of 13,890 kg, ensuring stability and strength during heavy-duty operations.

**Power:** Equipped with a powerful 86kW engine running at 2200rpm, this excavator is not only powerful but also reliable, providing consistent performance throughout the day.

**Rated Bucket Capacity:** With a rated bucket capacity of 0.6m³, the ZG150 is capable of handling large volumes of material, increasing productivity and efficiency on the job site.

### Engine Specifications:

**Model:** The Cummins QSF3.8-C115 is a force to be reckoned with. This new generation high-power EFI engine is designed to meet the demands of heavy-duty applications.

**Type:** A four-cylinder in-line, four-stroke turbocharger ensures that the engine delivers power smoothly and efficiently.

**Emission:** Adhering to National Ⅲ standards, this engine is environmentally friendly, making the ZG150 a responsible choice for projects with sustainability goals.

**Cooling Method:** Water-cooled for optimal performance and longevity, the engine maintains a consistent temperature under heavy loads.

**Bore Diameter × Stroke:** With dimensions of 102×115 mm, the engine's design maximizes power output while ensuring durability.

**Displacement:** A generous 3.76 L displacement means the engine can handle high workloads without sacrificing efficiency.

**Rated Power:** The engine delivers a commendable 86KW at 2220RPM, providing a strong foundation for the ZG150's capabilities.

### Performance Features:

**New Generation Control System:** This advanced system optimizes hydraulic absorption power, ensuring comprehensive performance and responsiveness.

**Max. Traction:** The ZG150 can exert a maximum traction force of 122 KN, allowing it to handle tough terrain and heavy loads with ease.

**Traveling Speed:** With high and low traveling speeds of 5.9 km/hr and 3.4 km/hr respectively, this excavator can navigate job sites quickly and efficiently.

**Swing Speed:** A swift swing speed of 13 rpm enables the ZG150 to execute precise movements and complete tasks with agility.

**Gradeability:** Capable of climbing a 35-degree slope, the ZG150 demonstrates its versatility and adaptability in various terrains.

### Conclusion:

The ZG150 Crawler Hydraulic Excavator is more than just a machine; it's a powerhouse designed to tackle your toughest excavation challenges. With its powerful engine, robust build, and advanced control system, it's the ideal choice for professionals seeking a reliable and efficient excavation solution. Whether you're working on a construction site, mining operation, or any other heavy-duty project, the ZG150 is ready to deliver outstanding results.

In the world of heavy machinery, the ZG150 stands out for its combination of power, efficiency, and adaptability. It's not just about the numbers—it's about the capabilities. The ZG150 is a machine that promises to exceed expectations, delivering on the promise of advanced engineering and superior performance.
